Size:1180*1040*560CM

1, post material: to ensure that post in the severe environment used for a long time, the surface coating are destroyed, still can maintain higher oxidation resistance, do not produce rust phenomenon, the company provides the outdoor amusement equipment column material surface using electrostatic powder coating processing.

(1) column size: (thickness of 2.0 mm, diameter of 114 mm),

Follow the international major manufacturers specifications, achieve high resistance, tensile strength can reach 19.4 KGF/best callus induction

(2) surface treatment: (electrostatic non-toxic spraying)

Surface powder coating material with low metal content material in accordance with the safety standard ASTM F963 first - (Clasue 8.3) criterion, through the heavy metal content standard.

To prevent fading: powder coating material add resistance to ultraviolet stabilizer, ensure color bright keep long.

2, platform material: thickness of 2.0 mm cold rolling punch. Surface treatment: A, prevent slippery type plastic with overlap (plastic coated) B, resin paint (plastic)

(1) material size: 1165 cm steel material USES 2.0 mm cold rolled steel sheet,

(2) platform strength structure design: set drainage punching, prevent children from the game injured finger, accord with the United States to swim with safety standard ASTM and tour of Europe with safety standards EN 1176 part 1

(3) platform structure design: cross type bearing bottom steel sheet design, increase the load capacity.

3, metal (including steel tube, etc.) accessories material: thickness of 2.0 mm welded pipe, the surface treatment: non-slip, electrostatic spraying

(1) material: adopt international companies share specification 2.0 mm thickness, both inside and outside galvanized steel pipe. Make sure the strength and safety.

Surface treatment: electrostatic non-slip surface spraying, and with galvanized steel pipe as the backing material, plus surface heat treatment and electrostatic non-toxic powder coating. Galvanized and powder coating, double surface coating, prolong the surface protection coating life and steel pipe oxidation time.

(2) to prevent fade: powder coating material add resistance to ultraviolet stabilizer, ensure color bright keep long.

4, plastic accessories material: engineering plastics to add resistance to stop outside stability and antistatic agent, surface treatment: die casting surface

(1) raw material: adopt import South Korea's samsung polyethylene material. CONTENE adopted professional COMPOOUND technology, will color powder and polyethylene base material fully mixed, let rotomolding production can fully will color and base material are inseparable, let resistance to ultraviolet ray, fade, and embrittlement, static element such as long does not leak. And general factory is will color powder and polyethylene base material to dry mixing mode mixing have great performance respectively. The color three years does not fade, resistance to ultraviolet light fastness of 8 level.

(2) the mold surface treatment: adopt casting surface processing, show higher yield and quality feeling and scratch resistant property.

(3) tensile strength: 163 KGF/cm3, bending strength: 133 KGF, deformation temperature: 65.1 degrees c, density: 0.92 g/cm3

5, clamp ring material: aluminum alloy. Surface treatment: mechanical polishing

(1) material: aluminum alloy injection forming

(2) surface treatment: mechanical surface polishing, the surface powder coating.

6, fasteners: stainless steel round head or T flat screw. Surface treatment: mechanical polishing

(1) material: stainless steel material types: the round head hex safety screw and T flush Allen screw. Screw hole center a salient point design, general tools can't loose, can prevent any adjustment function.
